Rolls

quality flaking, cracking and grinding rolls

Throughout our more than 100-years history, we have been gaining experience based on the know-how together with the needed prestige to manufacture rolls which fulfill the sector needs.

As a result of our success, our high quality flaking, cracking and grinding rolls are exported to more than 130 countries in the world, not only for our final clients but also for OEM´s .This figure shows the confidence of food processing machinery manufacturers placed in Balaguer. These manufacturers believe Balaguer Rolls is the best company to purchase the highest quality rolls.

In addition, it is important to highlight that the maximum diameter in which we manufacture rolls is 1200 mm, which proves our commitment to excellence and our ability to adapt to different specifications and market requirements.

Download corporate catalog

Gallery

Flour
Balaguer qualities	k00 480-530 HB K36 510-550 HB K12 550-600 HB K01 420-470 HB K02 380-430 HB CRONOS (K06) 350-430 HB
Rolls available	220-300 mm
Length	L ≤1500
Chill Depth	Chill Depth Range from 8 to 50 mm

Oil roll
Balaguer qualities	Cracking rolls
	K00 480-530 HB K36 510-550 HB K70 540-580 HB
	Flaking rolls
	K00 480-530 HB K04 540-580 HB K70 540-580 HB BBR 380-450 HB IBR-S 420-460 HB IBR-H 460-510 HB
Rolls available	250-1200 mm
Length	L ≤3000
Chill Depth	Chill Depth Range from 8 to 50 mm

Café
Balaguer qualities	K00 480-530 HB K36 510-550 HB K12 550-600 HB K28 520-590 HB
Rolls available	150-306 mm
Length	L ≤1500
Chill Depth	Chill Depth Range from 8 to 50 mm

Chocolate
Balaguer qualities	K00 480-530 HB K04 540-580 HB
Rolls available	300-500 mm
Length	L ≤3000
Chill Depth	Chill Depth Range from 8 to 50 mm

Malt brewery roll
Balaguer qualities	K00 480-530 HB K36 510-550 HB K12 550-600 HB K28 520-590 HB
Rolls available	200-600 mm
Length	L ≤2500
Chill Depth	Chill Depth Range from 8 to 50 mm

Galletas
Balaguer qualities	K00 480-530 HB K28 520-590 HB
Rolls available	150-600 mm
Length	L ≤2500
Chill Depth	Chill Depth Range from 8 to 50 mm

Piensos
Balaguer qualities	K00 480-530 HB K36 510-550 HB K12 550-600 HB K58 470-520 HB IBR-S 420-460 HB IBR-H 460-510 HB
Rolls available	150-1200 mm
Length	L ≤3000
Chill Depth	Chill Depth Range from 8 to 50 mm

Fertilizante
Balaguer qualities	K00 480-530 HB K36 510-550 HB K12 550-600 HB K28 520-590 HB K70 540-580 HB
Rolls available	200-1200 mm
Length	L ≤3000
Chill Depth	Chill Depth Range from 8 to 50 mm

Pintura
Balaguer qualities	K00 480-530 HB K36 510-550 HB K12 550-600 HB
Rolls available	180-500 mm
Length	L ≤2500
Chill Depth	Chill Depth Range from 8 to 50 mm

Jabón
Balaguer qualities	K00 480-530 HB K36 510-550 HB K12 550-600 HB k28 520-590 HB
Rolls available	200-500 mm
Length	L ≤2500
Chill Depth	Chill Depth Range from 8 to 50 mm

Sal
Balaguer qualities	K00 480-530 HB K36 510 -550 HB K12 550 -600 HB K28 520 -590 HB
Rolls available	200-500 mm
Length	L ≤2000
Chill Depth	Chill Depth Range from 8 to 50 mm

Other Industries
Balaguer qualities
	K00 480-530 HB K36 ;510-550 HB K70 540-580 HBK00 480-530 HB K04 540-580 HB K70 540-580 HB BBR 380-450 HB IBR-S 420-460 HB IBR-H 460-510 HB K58 470-50 HB


Rolls available	250-1200 mm
Length	L ≤3000
Chill Depth	Chill Depth Range from 8 to 50 mm

Flour
Balaguer qualities	k00 480-530 HB K36 510-550 HB K12 550-600 HB K01 420-470 HB K02 380-430 HB CRONOS (K06) 350-430 HB
Rolls available	220-300 mm
Length	L ≤1500
Chill Depth	Chill Depth Range from 8 to 50 mm

Oil roll
Balaguer qualities	Cracking rolls
	K00 480-530 HB K36 510-550 HB K70 540-580 HB
	Flaking rolls
	K00 480-530 HB K04 540-580 HB K70 540-580 HB BBR 500-550 HB IBR-S 420-460 HB IBR-H 460-510 HB
Rolls available	250-1200 mm
Length	L ≤3000
Chill Depth	Chill Depth Range from 8 to 50 mm

Coffee
Balaguer qualities	K00 480-530 HB K36 510-550 HB K12 550-600 HB K28 520-590 HB
Rolls available	150-306 mm
Length	L ≤1500
Chill Depth	Chill Depth Range from 8 to 50 mm

Chocolate
Balaguer qualities	K00 480-530 HB K04 540-580 HB
Rolls available	300-500 mm
Length	L ≤3000
Chill Depth	Chill Depth Range from 8 to 50 mm

Malt brewery roll
Balaguer qualities	K00 480-530 HB K36 510-550 HB K12 550-600 HB K28 520-590 HB
Rolls available	200-600 mm
Length	L ≤2500
Chill Depth	Chill Depth Range from 8 to 50 mm

Biscuits
Balaguer qualities	K00 480-530 HB K28 520-590 HB
Rolls available	150-600 mm
Length	L ≤2500
Chill Depth	Chill Depth Range from 8 to 50 mm

Animal feed
Balaguer qualities	K00 480-530 HB K36 510-550 HB K12 550-600 HB K58 470-520 HB IBR-S 420-460 HB IBR-H 460-510 HB
Rolls available	150-1200 mm
Length	L ≤3000
Chill Depth	Chill Depth Range from 8 to 50 mm

Fertilizer
Balaguer qualities	K00 480-530 HB K36 510-550 HB K12 550-600 HB K28 520-590 HB K70 540-580 HB
Rolls available	200-1200 mm
Length	L ≤3000
Chill Depth	Chill Depth Range from 8 to 50 mm

Paint
Balaguer qualities	K00 480-530 HB K36 510-550 HB K12 550-600 HB
Rolls available	180-500 mm
Length	L ≤2500
Chill Depth	Chill Depth Range from 8 to 50 mm

Soap
Balaguer qualities	K00 480-530 HB K36 510-550 HB K12 550-600 HB k28 520-590 HB
Rolls available	200-500 mm
Length	L ≤2500
Chill Depth	Chill Depth Range from 8 to 50 mm

Salt
Balaguer qualities	K00 480-530 HB K36 510 -550 HB K12 550 -600 HB K28 520 -590 HB
Rolls available	200-500 mm
Length	L ≤2000
Chill Depth	Chill Depth Range from 8 to 50 mm

			Flaking rolls
	Flour Milling	Animal Feed milling roll	Edible Oil roll	Coffe roll	Chocolate refiner roll	Malt brewery roll	Biscuit roll	Salt	Fertilizer roll	Paints	Soap roll
Balaguers qualities	k00 480-530 HB K36 510-550 HB K12 550-600 HB K01 420-470 HB K02 380-430 HB CRONOS(K06) 350-430 HB	k00 480-530 HB k36 510-550 HB k12 550-600 HB k58 470-520 HB IBR-S 420-460HB IBR-H460-510HB	Cracking rolls	k00 480-530 HB k36 510-550 HB k12 550-600 HB k28 520-590 HB	k00 480-530 HB k04 540-580 HB	k00 480-530 HB k36 510-550 HB k12 550-600 HB k28 520-590 HB	k00 480-530 HB k28 520-590 HB	k00 480-530 HB k36 510 -550 HB k12 550 -600 HB k28 520 -590 HB	k00 480-530 HB k36 510-550 HB k12 550-600 HB k28 520-590 HB k70 540-580 HB	k00 480-530 HB k36 510-550 HB k12 550-600 HB	k00 480-530 HB k36 510-550 HB k12 550 -600 HB k28 520-590 HB
			k00 480-530 HB k36 510-550 HB k70 540-580 HB
			k00 480-530 HB k70 540-580 HB IBR-S 420-460HB IBR-H 460-510HB BBR 500-550 HB
Rolls available	220-300mm	150-812mm	250-812mm	150-306mm	300-500mm	200-600mm	150-600mm	200-500mm	200-812mm	180-500mm	200-500mm
Length	L≤1500mm	L<3000mm	L<3000mm	L≤1500mm	L≤3000mm	L≤2500mm	L≤2500mm	L≤2000mm	L≤3000mm	L≤2500mm	L≤2500mm
Chill Depth	Chill Deph Range from 8 to 50 mm
